A Richmond bathroom can sit in a listed eighteenth century house, a St Matthias villa or an Alberts terrace; where the house is listed, the plan resists losing original layout or features.
A bathroom in a retained Georgian interior
For a Richmond Hill or Richmond Green period bathroom, record the floor, plaster and joinery that will remain before selecting lining and waterproofing methods. Establish drainage and extraction without assuming that historic walls can be chased. If the room is at ground or lower-ground level near the river, assess site-specific flood risk before choosing finishes and service positions.
A Richmond bathroom: drainage, damp and the rooms below
In a terrace of three storeys over a basement, such as 28–40 Richmond Hill, which Historic England lists, the soil stack route often decides where a new bathroom can go. A room far from the stack needs a waste run with enough fall across the joists, so check both before fixing a layout.
Source: Historic England: 28–40 Richmond Hill, Grade II · When Building Regulations approval is needed
In a flat within a converted house, locate the shared stack and its isolation valves, and agree how the ceiling of the flat below could be opened if a leak is suspected. Settle falls, waterproofing and extraction ahead of tiles, and trace any damp to its cause.
Source: LEASE: alterations and home improvements
A bathroom in an existing basement room needs its damp, drainage and ventilation checked first. Most points checked in the town lie outside Flood Zones 2 and 3 on Environment Agency data, but Old Palace Lane and the riverside end of Friars Lane read Zone 3, so check the address on the flood map for planning.
Source: Environment Agency: Flood Zones 2 and 3 (rivers and sea) data · GOV.UK: flood map for planning, checked by address
Approvals to check for a Richmond bathroom
A bathroom can need Building Regulations approval for new plumbing, electrics near a bath or shower, or heating work. Richmond's building control, where Richmond is the council for the address, offers Building Notice, Full Plans and Regularisation routes; agree which covers each element and who arranges inspections before pipes and cables are boxed in.
Source: When Building Regulations approval is needed · GOV.UK: Building Regulations approval · Richmond: how to make a Building Regulations application · Find the council for the property
Historic England lists terraces on the Green such as Maids of Honour Row and Old Palace Terrace, so check the national list first. In a listed house, ask whether new pipe runs need consent, which Richmond applies inside a building as well as outside. Where the 2000 direction applies, a new extract grille facing a highway or open space can need permission.
Source: Historic England: listed-building consent · Historic England: 1–4 Maids of Honour Row, Richmond Green, Grade I · Historic England: 2 to 6 Old Palace Terrace, Richmond Green, Grade II* · Richmond: listed buildings · Article 4 direction 2000: Old Palace Lane, Park Road, Halford Road and other addresses
In a leasehold flat, read whether the landlord or freeholder must consent in writing before services or floors change, and on what terms. Refitting a bathroom does not by itself bring in the Party Wall Act; notice arises only with qualifying work, for example cutting into the wall shared with next door.
Source: LEASE: alterations and home improvements · Party-wall work requiring notice
Sequencing a bathroom refit in Richmond
Source: Richmond: construction noise and permitted hours · LEASE: alterations and home improvements · Find the council for the property
Measure the route for a new bath, shower tray or stone from the street to the room, front steps and shared hall included, and protect it before anything is carried in. In a converted house, give the managing agent and neighbouring flats notice of each shut-off of the shared supply.
Source: LEASE: alterations and home improvements
Strip-out waste may justify a skip. On a council road it needs Richmond's skip licence, and any bay suspension has to be requested with notice; at the points checked on TfL's data, Lower Mortlake Road is a TfL road, where TfL issues the licences, while George Street, Sheen Road and Queen's Road are not.
Source: Richmond: apply for a skip licence · Richmond: parking suspensions · TfL: red routes and the TLRN map · TfL: highway licences on red routes
Briefing a contractor on a Richmond bathroom
Send the room's measurements, photographs and the floor it is on, and say whether the home is a whole house or a flat, and in what kind of building. Show the WC and basin connections, any outside extract vent, the ceiling below and any damp, and mark where you think the soil stack runs.
For a flat, attach the lease and the managing agent's rules for works; for any home, add earlier drawings and past listed building or building control decisions about the room. Note any list entry, conservation area or flood zone you know of, and whether a second bathroom stays usable.
Source: LEASE: alterations and home improvements
Keep the decided layout, sanitaryware and tiles apart from anything that waits on lifting the floor, a drainage survey or the managing agent's reply, and ask for those unknowns to be shown as provisional items. Name who arranges building control inspections and who deals with the freeholder.
Listed rooms, Sheen Road and the Alberts
In a listed house a bathroom is an alteration like any other. Policy 29 resists removing original structure, layout and features that contribute to significance, and it can require harmful later features to be taken out and lost ones reinstated as part of the work.
Sheen Road holds a concentration of listed buildings, most of them eighteenth century, and the south east and south west sides of Old Palace Square are terraces of listed town houses, so bathrooms there are fitted around the existing plan of the rooms.
In the Alberts, the 1870s terraces are two storeys high on narrow streets, where a bathroom has to fit within a small house's plan.
Wiring near a bath or shower is notifiable under Part P, needing a building notice or full plans unless the wiring is done by a member of a competent person scheme, and some new water fittings require notice to the water undertaker before they go in.
On the outside, replaced gutters and water pipes go in black, not grey, as the borough's guidance asks.
Outside Richmond: Royal Court House, Sloane Street, whose renovation of an apartment on Sloane Street took in marble bathrooms.
In a listed house we record a room's cornices, skirtings and floorboards before design, and route new pipes where they cause least loss.
Sources: Richmond upon Thames Local Plan 2024 to 2039 (adopted October 2025); Richmond: Richmond and Richmond Hill Village Planning Guidance SPD (June 2016); Approved Document P: Electrical safety, dwellings (2013 edition); GOV.UK: Building regulations approval; The Water Supply (Water Fittings) Regulations 1999, regulation 5; Richmond: House Extensions and External Alterations SPD (May 2015).
Bathroom Renovation in Richmond: Questions
Does a bathroom in a listed Richmond house need listed-building consent?
If it affects the building's special interest, yes, and that can include interiors. Richmond's plan asks that alterations rest on a proportionate understanding of the listed building and resists the loss of features that contribute to it.
How should a listed Richmond bathroom project be sequenced?
Record the room first, then design around what is significant, then apply for listed building consent, and only then strip out; nothing original is removed before consent is granted.
What does a bathroom involve in a grand Georgian house on Richmond Hill?
Working within an eighteenth century plan: the guidance describes the exceptional quality of Richmond Hill's eighteenth century architecture, and in a listed house the routes for pipes and ducts are chosen to keep original features.
Do you renovate bathrooms in riverside Richmond properties?
Yes. Below ground near the river, Richmond's flood policy applies: no bedrooms at basement level in the higher-hazard parts of Zone 3a, and any basement room needs internal access to a higher floor.
Is there further reading on Richmond bathrooms and heating?
Richmond's Village Planning Guidance for Richmond and Richmond Hill describes each conservation area and the materials that matter there, and the Local Plan encourages sympathetic energy and carbon savings in historic and listed buildings.
How much does a bathroom renovation cost in Richmond?
The final price depends on the scope, specification and complexity of the project. We provide a detailed fixed-price quotation after the initial consultation and design phase.
